Specificatons
Dimensions :151 × 108 × 132 mm
Weight (Lens Excluded): 449 g
Gimbal
Angular Vibration Range: ±0.005°
Mount: Detachable
Controllable Range: Tilt: +40° to -125°; Pan: ±300°; Roll: ±20°
Mechanical Range: Tilt: +50° to -130°; Pan: ±330°; Roll: +90° to -50°
Max Controllable Speed: Tilt: 180°/s; Roll: 180°/s; Pan: 360°/s
Camera
Sensor
- Sensor Size (Still): 23.5×15.7 mm
- Sensor Size (Max video recording area): 23.5×12.5 mm
- Effective Pixels: 24 MP
Supported Lenses
- DJI DL-S 16mm F2.8 ND ASPH (with lens hood and balancing ring/filter)
- DJI DL 24mm F2.8 LS ASPH (with lens hood and balancing ring/filter)
- DJI DL 35mm F2.8 LS ASPH (with lens hood and balancing ring/filter)
- DJI DL 50mm F2.8 LS ASPH (with lens hood and balancing ring/filter
Supported Micro SD/SSD Cards
- MicroSD: Class 10 or UHS-1 rating with a writing speed of 15 MB/s required; Max capacity: 128 GB
- SSD: DJI CINESSD
Photo Sizes
- 3:2 （6016 × 4008）
- 16:9（6016 × 3376）
- 4:3（5216 × 3912）
Photo Format
- DJI CINESSD: DNG
- Micro SD: DNG, JPEG, DNG+JPEG
Operation Modes; Capture, Record, Playback
Still Photography Modes
- Micro SD: Single Shot, Burst Shooting (3/5/7/10 shots), Auto Exposure Bracketing (3/5 bracketed shots at 0.7 EV bias), Interval
- SSD: RAW Burst (3/5/7/10/14/∞ frames), up to 20 fps when using RAW Burst (exact quantity is determined by storage card capacity and battery power level)
Shutter Speed
- Electronic Shutter Speed: 1/8000 – 8s
- Mechanical Shutter Speed: 1/1000 – 8s (DJI DL-S 16mm F2.8 ND ASPH not supported)
ISO Range
- Photo: 100 – 25600
- Video: 100 – 1600 (EI mode on); 100 – 6400 (EI mode off)
Camera Features
Exposure Mode: Auto, Manual, Shutter Priority, Aperture Priority
Exposure Compensation: ±3.0 (3 stops of light)
Metering: Center-Weighted Metering, Spot Metering (12 × 8 area selection)
AE Lock: Supported
White Balance: Auto, Sunny, Cloudy, Incandescent, Neon, Custom (2000 K – 10000 K)
Video Caption: Supported (AVC/HEVC)
PAL/NTSC: Supported
Ultrasonic Dust Removal: Supported
Temperature
Operating Temperature Range: -4 to 104° F (-20 to 40° C)
Storage Temperature Range: -4 to 140° F (-20 to 60° C)
Video
Video Formats
- CINESSD: CinemaDNG, ProRes
- Micro SD: MOV, MP4
Video Resolution
- Aspect Ratio 17:9
- CinemaDNG
- 6K: 6016×3200, 23.976p, 14-bit
- 6K: 6016×3200, 24/25/29.97/30p, 12-bit
- 5.4K: 5440×2880, 23.976/24p, 14-bit
- 4K DCI: 4096×2160, 23.976p, 14-bit
- 4K DCI: 4096×2160, 24/25/29.97/30/47.95/48p, 12-bit
- 3.9K: 3944×2088, 50/59.94p, 12-bit
- ProRes RAW
- 6K: 6016×3200, 23.976p, 14-bit
- 6K: 6016×3200, 24/25/29.97/30p, 12-bit
- 5.4K: 5440×2880, 23.976/24p, 14-bit
- 4K DCI: 4096×2160, 47.95/48p, 12-bit
- ProRes RAW HQ
- 6K: 6016×3200, 23.976p, 14-bit
- ProRes
- 4K DCI: 4096×2160, 23.976/24/25/29.97/30p, 10-bit, HQ
- 2K: 2048×1080, 47.95/50/59.94p, 10-bit, HQ/XQ
- H.264
- 4K DCI: 4096×2160, 24/25/30/48/50/59.94p
- H.265
- 4K DCI: 4096×2160, 24/25/30p
- HD: 1280×720, 24/25/30/48/50/59.94p
- Aspect Ratio 16:9
- CinemaDNG
- 6K: 5760×3240, 23.976p, 14-bit
- 6K: 5760×3240, 24/25/29.97/30p, 12-bit
- 5.1K: 5120×2880, 23.976/24p, 14-bit
- 4K Ultra HD: 3840×2160, 23.976p, 14-bit 4K Ultra HD: 3840×2160, 24/25/29.97/30/47.95/48p, 12-bit
- 3.7K: 3712×2088, 50/59.94, 12-bit
- ProRes RAW
- 6K: 5760×3240, 23.976p, 14-bit
- 6K: 5760×3240, 24/25/29.97/30p, 12-bit
- 5.1K: 5120×2880, 23.976/24p, 14-bit
- 4K Ultra HD: 3840×2160, 47.95/48p, 12-bit
- ProRes RAW HQ
- 6K: 5760×3240, 23.976p, 14-bit
- ProRes
- 4K Ultra HD: 3840×2160, 23.976/24/25/29.97p, 10-bit, HQ/XQ
- 2.7K: 2704×1520, 47.95/50/59.94p, 10-bit, HQ
- FHD:1920×1080, 47.95/50/59.94p, 10-bit, HQ/XQ
- H.264
- 4K Ultra HD: 3840×2160, 24/25/30/48/50/59.94p
- 2.7K: 2720×1530, 24/25/30/48/50/59.94p
- FHD: 1920×1080, 24/25/30/48/50/59.94p
- HD: 1280×720, 24/25/30/48/50/59.94p
- H.265
- 4K Ultra HD: 3840×2160, 24/25/30p
- 2.7K: 2720×1530, 24/25/30/48/50/59.94p
- FHD: 1920×1080, 24/25/30/48/50/59.94p
- Aspect Ratio 2.44:1
- CinemaDNG
- 5.2K: 5280×2160, 23.976p, 14-bit
- 5.2K: 5280×2160, 24/25/29.97/30/47.95/48p, 12-bit
- ProRes
- 5.2K: 5280×2160, 23.976/24/25/29.97/30p, 10-bit, HQ
- H.264/H.265
- 4K Ultra HD: 3840×1572, 30p
(FOV will be narrower when shooting at a high frame rate. For more information, please refer to the Zenmuse X7 User Manual.)
- LENS: DL-S 16mm, DL 24mm, DL 35mm, DL 50mm lenses.
- IMAGE SIZE: Up to 6016 × 4008 (photo), 6K (video).
- OPERATING FREQUENCY: Typically 2.4 GHz/5.8 GHz (Inspire 2).
- ISO Sensitivity: Photo: 100-25600; Video: 100-6400.
- Controllable Range: Tilt: +40° to -125°; Pan: ±300°; Roll: ±20°
- Max Controllable Speed: Tilt/Roll: 180°/s; Pan: 360°/s.
- Operating Temperature: -4°F to 104°F (-20°C to 40°C)
- Transmitter Power (EIRP): Up to 20 dBm (region-dependent).
- Video Format: CinemaDNG, ProRes, MOV, MP4.
- Remote Control: DJI Inspire 2 controller, 7 km range (FCC).
- Stabilization: ±0.005° angular vibration range.±0.005° angular vibration range
- Takeoff Weight: Approx. 3.4 kg (Inspire 2 with X7)
- Diagonal Distance: 605 mm (Inspire 2)
- Max Flight Distance: Up to 7 km
- Max Ascent Speed: 6 m/s
- Max Descent Speed: 5 m/s
- Max speed (Near Sea Level): 58 mph (94 kph) near sea level
- Max Service Ceiling Above Sea Level: 5000 m
- Max Flight Time: 23-27 minutes
- Max Pitch Angle: 40° (S-mode
- Max Angular Velocity: Yaw: 150°/s
- Global Navigation Satellite System: GPS + GLON ASS
- Angular Vibration Range: ±0.005°
- Sensing System: Forward, downward, and upward sensors
- Camera Sensor: Super 35, 24 MP
- Shutter Speed: Electronic: 1/ 00-8s; Mechanical: 1/1000-8s
- Still Photography Mode: Single, Burst, AEB, Interval, RAW Burst
- Video Resolution: Up to 6K CinemaDNG/ProRes
- Photo Format: DNG (RAW), JPEG, DNG+JPEG
- Aircraft Dimension: 151 × 108 × 132 mm
- Hovering Accuracy Range: Vertical: ±0.5 m; Horizontal: ±1.5 m
- Gimbal Mechanical Range: Tilt: +50° to -130°; Pan: ±330°; Roll: +90° to -50°
- Image Resolution: Up to 6016 × 4008 (photo)
